The TIGERINST LFSS40L-S is a compact industrial gauge for applications where the process fluid requires stainless steel wet components. This gauge features a stainless steel case and can be filled with glycerine to prolong the life of the internal mechanism when exposed to vibration. It is calibrated to 1% full scale accuracy and is suitable for many industrial and processing applications.

4″ Liquid Filled Industrial Gauge

The TIGERINST LFSS40L-S is a compact industrial gauge for applications where the process fluid requires stainless steel wet components. This gauge features a stainless steel case and can be filled with glycerine to prolong the life of the internal mechanism when exposed to vibration. It is calibrated to 1% full scale accuracy and is suitable for many industrial and processing applications.

CAUTION: A coil syphon must be installed on the connection when used on steam applications

CASE:304 Stainless steel

RING:Stainless steel, internal rotation LENS:Reinforced glass or Safety Glass DIAL:Aluminum, white finished with black markings POINTER:Aluminum, black, micro-adjustable MOVEMENT:Stainless steel TUBE&SOCKET:316 Stainless steel CONNECTION:1/2"NPT or 1/4"NPT ACCURACY:±1% Full Scale (ASME B40.100 Grade 1A) PROCESS TEMPERATURE:-40 to 140°F (-40 to 60°C)
